Información adicional
| Rated operation current Ie at 40 °C Tu | 470 |
|---|---|
| Rated operating voltage Ue | 200 |
| Rated power three-phase motor, inline, at 230 V | 132.0 |
| Rated power three-phase motor, inline, at 400 V | 250.0 |
| Rated power three-phase motor, inside delta, at 230 V | 250.0 |
| Rated power three-phase motor, inside delta, at 400 V | 400.0 |
| Function | Single direction |
| Internal bypass | true |
| Torque control | false |
| Rated surrounding temperature without derating | 40 |
| Rated control supply voltage Us at AC 50HZ | 110 |
| Rated control supply voltage Us at AC 60HZ | 110 |
| Voltage type for actuating | AC |
| Release class | Adjustable |
| Degree of protection (IP) | IP00 |
