Información adicional
| Rated control supply voltage Us at AC 50HZ | 110.0 |
|---|---|
| Rated operation current Ie at AC-4, 400 V | 230 |
| Rated control supply voltage Us at AC 60HZ | 110.0 |
| Rated control supply voltage Us at DC | 110 |
| Voltage type for actuating | AC/DC |
| Number of main contacts as normally open contact | 3 |
| Rated operation power at AC-3, 400 V | 132.0 |
| Rated operation current Ie at AC-1, 400 V | 330 |
| Rated operation current Ie at AC-3, 400 V | 265 |
| Rated operation power at AC-4, 400 V | 132.0 |
| Rated operation power NEMA | 147.09975 |
| Modular version | true |
| Number of auxiliary contacts as normally open contact | 2 |
| Number of auxiliary contacts as normally closed contact | 2 |
| Type of electrical connection of main circuit | Rail connection |
| Código Berdin | 06360735 |
