Información adicional
| Rated control supply voltage Us at AC 50HZ | 220.0 |
|---|---|
| Rated control supply voltage Us at AC 60HZ | 220.0 |
| Voltage type for actuating | AC |
| Rated operation current Ie at AC-1, 400 V | 910 |
| Rated operation current Ie at AC-3, 400 V | 820 |
| Rated operation power at AC-3, 400 V | 450.0 |
| Rated operation current Ie at AC-4, 400 V | 690 |
| Rated operation power NEMA | 514.849125 |
| Modular version | true |
| Number of auxiliary contacts as normally open contact | 3 |
| Number of auxiliary contacts as normally closed contact | 3 |
| Number of normally closed contacts as main contact | 0 |
| Number of main contacts as normally open contact | 3 |
