Información adicional
| With status indication | false |
|---|---|
| Rated operation current Ie at DC-13, 24 V | 3 |
| Explosion safety category for dust | None |
| Explosion safety category for gas | None |
| Type of electric connection | Cable entry metrical |
| Type of interface for safety communication | None |
| Type of interface | None |
| Coating housing | Uncoated |
| Material housing | Plastic |
| Construction type housing | Special construction |
| Rated operation current Ie at DC-13, 125 V | 0.55 |
| Rated operation current Ie at AC-15, 24 V | 6 |
| Suitable for safety functions | true |
| Type of switching contact | Slow-action switch |
| Number of contacts as change-over contact | 0 |
| Number of safety auxiliary contacts | 4 |
| Length of sensor | 185.0 |
| Height of sensor | 43.5 |
| Width sensor | 54.0 |
| Rated control supply voltage Us magnet drive at DC | 24 |
| Type of guard locking | Quiescent current principle |
| With escape release | false |
| Guard locking force | 1300 |
| Ambient temperature during operating | -40 |
