Información adicional
| Number of poles (total) | 2 |
|---|---|
| Ambient temperature during operating | -25 |
| Concurrently switching N-neutral | true |
| Number of protected poles | 1 |
| Release characteristic | B |
| Pollution degree | 2 |
| Anti-nuisance tripping version | true |
| Width in number of modular spacings | 2 |
| Over voltage category | 3 |
| Suitable for flush-mounted installation | true |
| Degree of protection (IP) | IP20 |
| Rated current | 6 |
| Connectable conductor cross section solid-core | 0.75 |
| With interlocking device | true |
| Voltage type | AC |
| Current limiting class | 3 |
| Connectable conductor cross section multi-wired | 0.75 |
| Frequency | 50 |
| Rated voltage | 230 |
| Rated impulse withstand voltage Uimp | 4.0 |
| Rated short-circuit breaking capacity IEC 60947-2 | 35.0 |
| Rated fault current | 0.03 |
| Rated insulation voltage Ui | 264 |
| Rated short-circuit breaking capacity acc. EN 61009 | 10.0 |
| Rated short-circuit breaking capacity Icn acc. EN 61009-1 | 10.0 |
| Built-in depth | 70.0 |
| Surge current capacity | 1.0 |
| Código Berdin | 90175846 |
