Información adicional
| Model | Other |
|---|---|
| Switching function | monostable |
| Rated control supply voltage Us at AC 50HZ | 110.0 |
| Rated control supply voltage Us at AC 60HZ | 110.0 |
| Rated control supply voltage Us at DC | 110 |
| Voltage type for actuating | AC/DC |
| Number of analogue inputs | 0 |
| Number of analogue outputs | 0 |
| Number of outputs, with contact | 2 |
| Number of electronic outputs | 0 |
| Number of binary inputs | 4 |
| Input for thermistor connection | false |
| Input for earth fault detection | true |
| Input for analogue temperature sensor | true |
| Type of electrical connection for auxiliary- and control current circuit | screw-type terminals |
| Degree of protection (IP) | IP20 |
