Información adicional
| Type of electric connection | screw-type terminals |
|---|---|
| Voltage type for actuating | AC/DC |
| Current measurement range | 0.003 |
| Width | 22.5 |
| Max. permitted delay-on energization time | 20 |
| Min. adjustable off-delay time | 0.1 |
| Number of contacts as normally closed contact | 0 |
| Max. permitted off-delay time | 20 |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 1 |
| Min. adjustable delay-on energization time | 0.1 |
| Height | 92.0 |
| Rated control supply voltage Us at DC | 20.4 |
| With detachable clamps | true |
| Rated control supply voltage Us at AC 60HZ | 20.4 |
| Rated control supply voltage Us at AC 50HZ | 20.4 |
| Depth | 91.0 |
| Contains function DC-voltage over current | true |
| Three-phase under current possible | false |
| Single-phase over current possible | true |
| Single-phase hysteresis possible | false |
| Three-phase over current possible | false |
| Three-phase hysteresis possible | false |
| Contains function DC-voltage under current | true |
| Single-phase under current possible | true |
| Function DC-current hysteresis | true |
| Código Berdin | 90182082 |
