Información adicional
| Type of electric connection | Screw connection |
|---|---|
| Number of outputs, signalling function, delayed, with contact | 1 |
| Height | 86.0 |
| Width | 22.5 |
| With approval according to UL | true |
| With approval for BG BIA | false |
| With approval for TÜV | false |
| Performance level acc. EN ISO 13849-1 | None |
| SIL according to IEC 61508 | None |
| Category according to EN 954-1 | None |
| Suitable for safety functions | false |
| Number of outputs, signalling function, delayed, semiconductors | 0 |
| Number of outputs, signalling function, undelayed, semiconductors | 0 |
| Number of outputs, signalling function, undelayed, with contact | 0 |
| Rated control supply voltage Us at AC 50HZ | 24.0 |
| Number of outputs, safety related, delayed, semiconductors | 0 |
| Number of outputs, safety related, undelayed, semiconductors | 0 |
| Number of outputs, safety related, delayed, with contact | 0 |
| Number of outputs, safety related, undelayed, with contact | 0 |
| With feedback circuit | false |
| Rated operating frequency | 50 |
| Function standstill monitoring | false |
| Function rotational speed monitoring | true |
| With detachable clamps | true |
| Voltage type for actuating | AC/DC |
| Rated control supply voltage Us at DC | 24 |
| Rated control supply voltage Us at AC 60HZ | 24.0 |
| Depth | 102.0 |
