Información adicional
| Function delay-on energization | true |
|---|---|
| Suitable for remote control | false |
| Height | 90.0 |
| Voltage type for actuating | AC/DC |
| Suitable for front mounting | false |
| Suitable for DIN rail (top hat rail) mounting | false |
| With semiconductor output | false |
| Number of outputs, delayed, change-over contact | 1 |
| Outputs, reversible delayed/undelayed | false |
| Rated control supply voltage Us at DC | 12 |
| Number of outputs, delayed, normally closed contact | 0 |
| Number of outputs, undelayed, change-over contact | 0 |
| Number of outputs, undelayed, normally open contact | 0 |
| Function delay on de-energization | false |
| Time range | 0.05 |
| Number of outputs, delayed, normally open contact | 0 |
| Function floating contact on energization | true |
| Width | 17.5 |
| Clock function, starting with pause, variable | false |
| Pluggable on auxiliary contact block | false |
| Number of outputs, undelayed, normally closed contact | 0 |
| Remote operation possible | false |
| With plug-in socket | false |
| Clock function, starting with pulse, variable | false |
| Rated control supply voltage Us at AC 50HZ | 12 |
| Function flashing, starting with pause, fixed time | true |
| Function flashing, starting with pulse, fixed time | false |
| Function pulse shaping | true |
| Function star-delta | false |
| Function floating contact on de-energization | true |
| Rated control supply voltage Us at AC 60HZ | 12 |
| Depth | 66.7 |
| Código Berdin | 90181438 |
