Información adicional
| Number of protected contact energized outputs | 1 |
|---|---|
| Max. output current at protected output | 250.0 |
| Suitable for safety functions | true |
| Switching distance | 12.0 |
| Cross-/short circuit identification possible | true |
| Voltage type | DC |
| Rated supply voltage at DC | 20.4 |
| Rated supply voltage at AC 60 Hz | 20.4 |
| Rated supply voltage at AC 50 Hz | 20.4 |
| Min. output current | 500.0 |
| Mechanical mounting condition for sensor | Concise |
| Ambient temperature | -25 |
| Performance level acc. EN ISO 13849-1 | Level e |
| Type of actuation | Transponder |
| Category according to EN 954-1 | 4 |
| Protected switch distance ON | 10.0 |
| Protected switch distance OFF | 16.0 |
| Material housing | Plastic |
| Explosion safety category for dust | None |
| Explosion safety category for gas | None |
| Length of sensor | 106.0 |
| Height of sensor | 22.0 |
| Width sensor | 25.0 |
| Type of electric connection | Connector M12 |
| Type of interface for safety communication | Other |
| Degree of protection (IP) | Other |
